                    |   AlphaServer 8200/8400 Firmware   |
                    |          Read Me First             |
                    +------------------------------------+

         1. Firmware Update Revisions - Last Release December 2002

         Firmware Update Bootfile "AS8000_V20.EXE"
         contains the SRM Console V6.4, which has the following
         components:

         SROM         V3.1
         VMS PALcode  V1.21-1
         UNIX PALcode V1.23-1
         ISP1020 FW   V5.57
         AlphaBIOS    5.70c

         I/O Option Firmware Revisions

         Option Name     Hardware Rev     Firmware Rev
         -----------     ------------     ------------
         CIPCA            All revs         A420
         CIXCD            All revs         7.0
         DEFAA            All revs         1.10
         DEFPA            All revs         3.20
         DEMFA            All revs         2.1
         DEMNA            All revs         9.4
         KFMSB            pre-C02          1.0
         KFMSB            C02              2.4
         KZMSA            F and greater    5.6
         KZPSA            All revs         A12


         2. Firmware Enhancements and New Features

         For a complete list of enhancements and new features,
         consult the AlphaServer 8200/8400 Firmware
         Release Notes.

         - Fixed problem with bootp using unsupported block sizes.

         3. Firmware Anomalies, Restrictions, and Workarounds

         For a complete list of firmware anomalies, restrictions,
         and workarounds, consult the Firmware Release Notes.

         The ECU utility is intermittent when run from the advanced mode of
         console. The utility will load and appear to function but will
         exhibit an intermittent hang when attempting to add a new device.
         Run the utilty from diagnostic mode. For example:

               P00>>>set mo diag
               Console is in diagnostic mode
               P00>>>configure dev *
               P00>>>runecu

         Do NOT attempt to update console firmware to a lower revision
         than shown below.  Installing a revision of firmware below
         the minimum required will render the CPU module INOPERABLE.
         In SOME cases, the Loadable Firmware Update utility will
         not allow the update, if attempted, and would give an error
         message.

           o  E2056-CA (Single-CPU, 300Mhz) Rev. H and above    V2.2-102

           o  E2056-DA (Dual-CPU, 300Mhz) Rev. P and above      V2.2-102

           o  E2061-CA (Single-CPU, 350Mhz) Rev. A and above    V3.0-9

           o  E2061-DA (Dual-CPU, 350Mhz) Rev. A and above      V3.0-9

           o  E2062-DA (Dual-CPU, 440Mhz) All Rev.'s            V4.0-4

           o  E2065-DA (Dual-CPU, 625Mhz) All Rev.'s            T5.1-18



         4. AlphaServer 8200/8400 Firmware Release Notes

        http://ftp.digital.com/pub/DEC/Alpha/firmware/readmes/as8x00.html


--------------------------------------------------------------------------

Part Description:                           DEC Part    V   Vendor Part
                                                Number:     C   Number:
    _______________________________________________________________________
    AC Input Box, 208V 30A 3-Phase              30-33798-01
    AC Input Box, 416V 16A 3-Phase              30-33798-02
    Adapter, 25-way EIA-232 to 6-way MMJ        H8575-A
    Baffle Assy                                 70-29331-01
    Backplane Assy * Need to order the
      Enclosure                                 70-30430-01
    Battery, Real Time Clock used on E2062-xx   21-32423-01
    Bezel, Floppy *RX26                         74-48827-01
    Bezel Assy, Main                            70-29360-01
    Cable, External Serial Console              17-01364-01
    Cable, SCSI, Y-Adapter (BN39A-0G) * New
      style, replaces 17-03822-01 (BN21W-0B)    17-04454-01
    Cable, IOP Hose *DWLAB, only needed with
      rev B02 Motherboard                       17-03085-01
    Cable, Power 48V LSB *Black                 17-03118-01
    Cable, Power 48V LSB *RED                   17-03118-02
    Card Cage/Backplane Assy *XMI plug-in
      unit assy                                 70-25882-01
    Catch, R-Latch                              74-42872-01
    Cable Assembly, Coaxial Control 4.5ft.
      *DWLAA 4.5 Hose Cable                     17-03085-02
    CD-ROM Drive, 5.25 in. 600MB                RRD46-AA
    Converter, DC-DC 48V to 5V 120A *XMI
      plug-in unit assy                         30-36009-01
    Converter, DC-DC 48V to Multi O/P 136W
      *XMI plug-in unit assy                    30-36010-01
    CPU, Dual Turbolaser 437MHz (KN7CE-AB)      E2062-DA
    CPU, Dual (EV5/350MHz)* Dual CPU Module     E2061-DA
    CPU, TurboLaser Uni-Processor EV5 350 MHz   E2061-CA
    CPU, Dual (EV5.6/625MHz) *KN7CF-AB          E2065-DA
    CPU, Dual EV6, 525Mhz                       KN7CG-AB
    CPU, Dual EV6.7 700MHz *As an Upgrade       3X-KN7CH-AB
    CPU, TurboLaser Dual, 4MB Cache, KN7CC-AB
      *Alpha 300MHz CPU                         E2056-DA
    CPU, TurboLaser Single, 4MB Cache, KN7CC-AA
      *300MHz CPU                               E2056-CA
    CPU, TurboLaser Uni-Processor, 437MHz
      KN7CE-AA                                  E2062-CA
    Drive Assy, SCSI 1GB, 3.5in.                RZ26L-VA
    Drive Assy, SCSI 2.0GB, 3.5in.              RZ28-VA
    Diskette Drive, 2.88MB 3.5in.               RX26-AA
    Door, Rear *CPU Cabinet                     70-28584-01
    Door, Front *CPU Cabinet                    70-31071-01
    DWLPA, PCIA Daughter Board                  54-23470-01
    DWLPA, PCIA Mother Board                    54-23468-01
    Enclosure, SCSI StorageWorks Shelf          BA658-AA
    Fan, 48VDC w/Servo Control                  12-35173-01
    Fan, DWLPB Expansion Box                    12-23609-19
    FDDI, Twisted Pair Daughter Board           54-22501-01
    FDDI,  SAS Multi-mode Fiber Daughter        54-23835-01
    Foam, Front Cab                             74-43948-01
    Foam, Side Cab                              74-43947-01
    Future Bus Plug-in Unit, 48VDC              BA653-AA
    Graphics Console, Windows NT Subsystem      KFE72-AA
    Header Card Assy (CIXCD)                    54-20225-01
    Key, Console                                74-43945-01
    Local Disk Converter *LDC                   54-20868-01
    Memory, 8MB SIMM *Used on MS7CC-BA,
      MS7CC-CA and MS7CC-UA                     54-21724-01
    Memory, 32MB SIMM *Used on MS7CC-DA,
      MS7CC-EA and MS7CC-UB                     54-21726-01
    Memory, 64MB SIMM *Used on MS7AA-FA
      and MS7CC-FA                              54-21718-01
    Memory, 128MB Option                        MS7CC-BA
    Memory, 256MB Option                        MS7CC-CA
    Memory, 512MB Option                        MS7CC-DA
    Memory, 1GB Option                          MS7CC-EA
    Memory, 2GB Option                          MS7CC-FA
    Memory, 4GB Option *Qty 36 54-24723-01      MS7CC-GA
    Memory, Motherboard 1GB Turbo-Laser         E2035-AA
    Module, PCI to Memory Channel controller
      Single Port *CCMAA-BA Linecard V1.5       54-23663-02
    Module, Beeper                              54-23491-01
    Module, Cabinet Control Logic (CCL)         54-20300-01
    Module, Clock (75MHz), 300MHz TurboLaser    54-21728-05
    Module, Clock (87MHz), 350MHz TurboLaser    54-21728-06
    Module, Clock, 437MHz *used with E2062-CA
      (KN7CE) or E2062-DA (KN7CE)
      or E2065-DA(KN7CF)                        54-24776-01
    Module, Clock/Arbitration (XMI Backplane)   T2030-YA
    Module, DWLPB PCIS Daughter                 54-23470-02
    Module, DWLPB PCIA Main *w/Memory Channel   54-24721-01
    Module, EISA 2-Line Sync Comm (DNSES-AA)    54-23279-01
    Module, EISA Pronet 4/16 Token Ring Adapter
      (DW300)                                   29-29555-01 PD  12-412520-00
    Module,PCI-EISA Standard I/O, Network       B2110-AA
    Module, FDDI/PCI DAS Adapter (DEFPA-DA)     54-22499-01
    Module, FDDI/PCI SAS Adapter (DEFPA-AA)     54-22499-02
    Module, FDDI/PMC SAS Adapter (DEFPZ)        54-22501-01
    Module, FDDI/PCI UTP Adapter (DEFPA-UA)     54-22499-03
    Module, Future Bus Bridge (DWLAA)           B2003-AA
    Module, I/O Port (KFTIA-AA) *ITIOP          E2054-AA
    Module, I/O TurboLaser (KFTHA-AA)           E2052-AA
    Module, Interface LASER to XMI *Lamb        T2028-AA
    Module, Memory Motherboard                  E2035-AA
    Module, Memory Motherboard *2GB             E2036-AA
    Module, Turbo Laser Terminator              E2034-AA
    Module, XMI to CI Adapter (CIXCD)           T2080-YA
    Module, XMI to NI Controller (DEMNA-M)      T2020-00
    Module, XMI to SCSI (KZMSA)                 T2029-AB
    NVRAM Daughter Board w/Prestoserve          DJ-ML300-BA
    Operator Control Panel *CPU Cabinet         54-20306-01
    PCI Plug in Unit (PIU) *1st for Sys Cab     DWLPB-BA
    PCI Plug in Unit (PIU) *2nd for Sys Cab,
      mounts in DWLPB-BA                        DWLPB-BA
    PCI Plug in Unit (PIU) *1st in Exp. Cab     DWLPB-BA
    PCI Plug in Unit (PIU) *2nd in Exp. Cab
      mounts in DWLPB-BA                        DWLPB-BA
    Power Supply, 120VAC 30A                    30-33796-01
    Power Supply, 240VAC 16A                    30-33796-02
    Solid State Disk Drive (SSD), 205MB         EF52R-AF
    Tape Drive, 8GB DAT                         TLZ07-VA
    Tape Drive, 20GB SCSI Single Ended          TZ87-VA
    Trim Kit, Bottom, 800mm                     H9C02-UC
